SEFOWOD High Torque Nema 23 Stepper Motor STM57112 3.6Nm/509.8oz.in 4.2A Bipolar 1.8° Precision 112mm Body for 3D Printers, CNC, Engraving Machines
2
sold in last
8
hours
Out of stock
$39.99
[Specifications]: Body Length: 112mm /4.41 inch; Step Angle: 1.8 degree; Phase: 2; Rated Current: 4.2A; Holding Togque: 3.6Nm (509.92 oz.in); Rotor Inertia: 810g.cm²; Weight: Single one is 1.68kg(3.70 pounds). [Size]: Nema 23 Bipolar Stepper Motor: 57x57x112MM (2.24x2.24x4.41 inch), Shaft Diameter: Φ 8mm ( D Shaft Φ 7.5mm ), Shaft Length:...
customers are viewing this product
- [Specifications]: Body Length: 112mm /4.41 inch; Step Angle: 1.8 degree; Phase: 2; Rated Current: 4.2A; Holding Togque: 3.6Nm (509.92 oz.in); Rotor Inertia: 810g.cm²; Weight: Single one is 1.68kg(3.70 pounds).
- [Size]: Nema 23 Bipolar Stepper Motor: 57x57x112MM (2.24x2.24x4.41 inch), Shaft Diameter: Φ 8mm ( D Shaft Φ 7.5mm ), Shaft Length: 21mm, 2 phase, 4 wires: Black (A+), Green (A-), Red (B+), Blue (B-).
- [High Torque]: The NEMA 23 stepper motor excels in delivering substantial torque when driven effectively, making it suitable for applications that demand significant power.
- [Applications]: The 57x57x112mm stepper motor finds extensive use across various industries, including 3D printing, CNC machining, laser engraving, medical equipment, and a multitude of automation systems, showcasing its versatility and reliability in diverse applications.
- [Packing List]: Include 1PCS 112MM Nema 23 stepper motor with a 80cm cable. Our customer service team is available to assist you with any questions or concerns.
